2.60 Lac - 2.90 Lac / piece
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Distributor, Importer |
| Automatic Grade | Manual |
| Application | Cutting Plywood |
| Voltage | 220V |
| Click to view more | |
Product Details
Sliding Table Length
3200 Mm
Sliding Table Width
380 Mm
Max. Diameter Saw Blade
355 X 30 Mm
Saw Blade Speed
5000 RPM
Tilting of Saw Blade
45 Degree C
Max. Cutting Depth at 90 Degree
85 Mm
Max. Cutting Depth at 45 Degree
50 Mm
Up-Down movement of saw blade
Manual
Motor For Saw Blade
5 HP
Max. Diameter Scoring Blade
120 X 20 Mm
Scoring Blade Speed
8000 RPM
Max. Depth of Cut off Scoring Blade
5 Mm
Motor For Scoring Unit
1 HP
Cutting Width / Rip Capacity
1250 Mm
Machine Dimension (L x B x H)
3250 X 3250 X 900 Mm
Features
- Burr free cutting & right angle cutting.
- Sturdily built heavy duty m/c that suit Indian working condition for precise cut with burr free cutting.
- Can 45 degree for degree cutting, also can read digital and manual.
- Lifting and tilting of saw unit by hand wheels both on front side for more convenience.
- Extra support for wood sheet and high accurate cutting.
- High precision and long life sliding table for work.
- Innovative detail solutions.
- Intuitive application concepts with Modern and distinct design.
- Complete package: Comprehensive service support.
- Made in India with best service support & very economical spares
