7.25 Lac / piece
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Distributor, Importer |
| Country of Origin | Made In India |
| Material | Pvc |
| Color | Green |
| Click to view more | |
Product Details
Application
Home
Length
10Ft, 5Ft
Feature
Brightening Look, Durable, Stable Performance
Packaging Type
Plywood
Type
Pvc Strip
Air Pressure
0.6 Mpa
Model Name/number
STEB-360
Feeding Speed
13 Mm/min
Brand Name
Siddhtech Industry
Edge Band Thickness
3 Mm
Min Width of the Wood
80 Mm
Min Length of the Wood
160 Mm
The Glue Temperature
200 Degree C
Phases
3 Phases
Voltage
380V
Frequency
50 Hz
Specifications following:
v Gluing--- Edge cut---End Trimming---Fine Trimming----Scraping---Buffing
(With PLC +Touch screen DELTA)
v Delta HMI
v Thickness of the wood: 10-45mm Edge band thickness: 0.4-3mm
v Min width of the wood:≥80mm
v Min length of the wood:≥160mm
v Feeding speed: 13mm/min
v Air pressure: 0.6Mpa
v Power : 380V/50Hz3Phase
v Total Power :8KW
v The glue temperature: 180-200degree
